HMX Moonlight Silent Tactile Switch Factory Lubed (10PCS)
HMX Moonlight Silent Tactile Switch
- 3.3mm Short Travel: Raised bottom housing design reduces total travel to 3.3mm. A firmer silicone dampener provides a more defined bottom-out feel and shorter post-tactile travel.
- HMX Dual-Shot Silent Stem: POM + TPE dual-shot stem delivers a solid bottom-out while avoiding the mushy feel common in traditional silent switches.
- PA66 Top Housing: Pure PA66 top housing with textured return-contact points helps reduce rebound noise, creating a muted and refined sound profile.
- Early Tactile Bump: Features a pronounced early tactile event with crisp feedback, offering an excellent balance between quiet operation and typing satisfaction.
- Two Spring Options: Available in 37g, and 45g actuation forces
Specs: |
1 quantity = 10 switches |
|
Switch Type |
Tactile |
|
Designer |
SU LAB |
|
Mold |
New (L3) |
|
Manufacturer |
HMX |
|
Stem material |
POM+PTFE |
|
Top Housing |
PA66 |
|
Bottom Housing |
PA66 |
|
Operating Force |
37±2g/45±2g |
|
Bottom-out Force |
43±2g/53±2g |
| Pre-travel | 2.5mm |
| Total Travel | 3.3±0.2mm |
| Spring | 22mm KOS single-stage extended |
| Factory Lubed | Yes! Stem legs and stem sliders are covered with a very thin coat of 205g0. The spring and leaf are lubed with dry film. Everything else is dry. There is no lube in the bottom housing or anywhere near the stem pole. The chance that these get lube pooling issue is very small. |
HMX Moonlight Silent Tactile Switch
- 3.3mm Short Travel: Raised bottom housing design reduces total travel to 3.3mm. A firmer silicone dampener provides a more defined bottom-out feel and shorter post-tactile travel.
- HMX Dual-Shot Silent Stem: POM + TPE dual-shot stem delivers a solid bottom-out while avoiding the mushy feel common in traditional silent switches.
- PA66 Top Housing: Pure PA66 top housing with textured return-contact points helps reduce rebound noise, creating a muted and refined sound profile.
- Early Tactile Bump: Features a pronounced early tactile event with crisp feedback, offering an excellent balance between quiet operation and typing satisfaction.
- Two Spring Options: Available in 37g, and 45g actuation forces
Specs: |
1 quantity = 10 switches |
|
Switch Type |
Tactile |
|
Designer |
SU LAB |
|
Mold |
New (L3) |
|
Manufacturer |
HMX |
|
Stem material |
POM+PTFE |
|
Top Housing |
PA66 |
|
Bottom Housing |
PA66 |
|
Operating Force |
37±2g/45±2g |
|
Bottom-out Force |
43±2g/53±2g |
| Pre-travel | 2.5mm |
| Total Travel | 3.3±0.2mm |
| Spring | 22mm KOS single-stage extended |
| Factory Lubed | Yes! Stem legs and stem sliders are covered with a very thin coat of 205g0. The spring and leaf are lubed with dry film. Everything else is dry. There is no lube in the bottom housing or anywhere near the stem pole. The chance that these get lube pooling issue is very small. |
Select Spring Weight
From $1.47
Original: $4.20
-65%HMX Moonlight Silent Tactile Switch Factory Lubed (10PCS)—
$4.20
$1.47Description
